Name: HQ-M500 Series 40-500kVA modular online UPS
Model: HQ-M500 series
Brief:
Power range: 40～500kVA;
Module Capicity: 50kVA;
Configuration: 12 slots;
Application:
Data center, telecom, network, security, lab, metro, hospital, government, military, power, transportation, broadcasting, bank, university, scientific research, petrochemical etc.
Features:
l Full DSP digital control in the process of rectification, inverter, charging and discharging
l Intelligent battery management solution, adopted intelligent “third-order”battery charging and discharging management system, extend battery life
l Input power factor up to 0.999, input harmonic current: <3%, 3 level inverter ,system efficiency above 96.5%
l Intelligent system self-diagnosis, plentiful fault records, large history record storage capacity
l Friendly human machine interface, with big touch screen and keyboard, abundant information
l Three phase in, three phase out, double conversion online system, provide best electricity quality and load protection
l Modular design, supporting hot plug, conveniently maintain on-site
l Excellent load adaptability, overload and short circuit capability
l Digital circulation control technology, high reliability in parallel up to 3 racks,reaching 1800kVA
l Smart-sleep function, the system can intelligently shutdown some modules according to load ,achieving higher efficiency
l Multiple communication interface:RS232,RS485,USB, SNMP, AS400 and programmable dry contacts
l EPO function
l All PCB adopts three-proofing technology
Specification
| Model |
HQ-M300 |
HQ-M400 |
HQ-M500 |
| System Capacity |
300kVA |
500kVA |
|
| Power Module Capacity |
50kVA |
50kVA |
|
| No. of Modules |
6+1 |
10+2 |
|
| Main |
| Input Wiring |
3Ph+N+PE |
| Rated Voltage |
380/400/415VAC (line-line) |
| Input Power Factor |
>0.99 |
| Total Harmonic Distortion |
THDi<3% for linear full load, THDi<5% for nonlinear full load |
| Voltage Range |
304～478Vac(line-line) 100% load;
228V~304Vac (line-line) load derated from 100%-75% linearly
|
| Input Frequency |
40Hz～70Hz |
| Bypass |
| Rated Voltage |
380/400/415VAC (line-line) |
| Voltage Range |
Default Range +15%～-20%(+10%,+15%,+20%,+25%, +25%-10%,-15%, -20%, -30%,-40% can be set) |
| Input Frequency |
±1Hz,±3Hz,±5Hz can be set |
| Battery |
| Input Voltage |
±240VDC (the number of batteries can be selected from 30 to 44) |
| Charging Power |
20% * Power Module |
| Charging voltage accuracy |
±1% |
| Output |
| Rated Voltage |
380/400/415VAC (line-line) |
| Rated Frequency |
50/60Hz |
| Power Factor |
1.0(Option) |
| Voltage Accuracy |
≤±1.0%@Steady ；≤±5.0%@ Transient |
| Dynamic response |
<5% (20% - 80% -20% Step load) |
| Dynamic recovery time |
< 20ms (0% - 100% -0% Step load) |
| THDu |
THDu <1%(linear load),THDu<5%( non linear load), |
| Overload Capacity |
110% overload for 60 min; 125% overload for 10 min; 150% overload for 1 mins;
>150% overload for 200ms
|
| System |
| Efficiency |
>96.5% (Dual Switch mode) |
| Display |
10.4 inch Touch Screen+LCD+LED |
| IP |
IP20 |
| Environment |
Operating Temperature: 0-40℃；Relative Humidity 0-95%(No condensing) |
| Noise |
<55dB@1 meter away |
| Dimension ( WxDxH mm) and Weight (kg) |
| Cabinet Dimension |
600*1000*2000mm |
1000*1000*2000mm |
1000*1000*2000mm |
| Module Dimension |
510*700*135mm |
| Cabinet Weight |
350kg |
450kg |
450kg |
| Module Weight |
40kg |
44kg |
44kg |
Note: specification is subject to change without further notice.
